The indoor half of the system is where the summer bill leaks out
When an August FPL bill in Woodmere comes in a hundred dollars heavy and the thermostat hasn't moved, the outdoor unit gets the blame. Nine times in ten the trouble is in the attic.
What a heavy August bill is usually saying
FPL bills in Ormond Beach spike for a short list of reasons, and the air handler is on it more often than people expect. A blower motor with failing bearings draws more current to move less air. A coil furred with the mold film that grows on every indoor coil in a 73-degree-dew-point climate makes the compressor run longer for the same result. And an attic duct system from 1978, split at the seams and sagging between trusses, pulls 120-degree attic air into the return so the system is cooling the attic along with the house. None of those show up on the outdoor unit. All of them show up on the bill.
That is why an air handler replacement in this town is rarely a box swap. It is the moment the indoor half of the system, and the ductwork hanging off it, gets brought up to the standard the outdoor unit already meets.
Retrofit in a 1984 house versus a new build west of I-95
The median Ormond Beach house was built around 1984, and in ZIP 32176 the 1970s and 1980s account for close to half the housing stock. A retrofit into one of those houses in Woodmere, The Trails or Tymber Creek has a set of known problems: a return grille sized for a different era, flex duct that has lost its insulation, a drain line that runs uphill in one spot, and a cabinet sitting on the attic floor with no secondary pan under it. The new Lennox air handler fixes the cabinet; the visit has to fix the rest, or the new unit inherits the old unit’s bill.
A new-construction install in Hunter’s Ridge or Plantation Bay is the opposite job. The ductwork is sized by design, the return is where it should be, and the air handler can be placed in a conditioned closet from day one. The challenge there is a house so tight that it needs controlled fresh air, which the air handler can provide if the ventilation equipment is planned with it rather than bolted on later.
Ductwork realities in Ormond Beach homes
Three duct problems come up on most of our Volusia attic visits:
- The undersized return. The single hallway grille in a 1970s ranch cannot feed a modern coil. The blower starves, the coil runs cold, and ice forms in July. One or two added returns are the fix.
- Leaks on the return side. Every gap on the suction side of the system pulls hot, humid attic air into the house. Sealing those seams does more for humidity than any upgrade to the equipment.
- Supply runs that never reached the addition. The Florida room added to an Ormond Terrace ranch in 1995, or the bonus room over a Breakaway Trails garage, often hangs off the end of a run that was never sized for it. Sometimes the fix is a bigger run; sometimes it is a mini-split and leaving the main system alone.
Sizing the indoor unit
An air handler is sized by airflow, not by guesswork, and the airflow has to match both the outdoor unit and the ducts. We run a load calculation on the house, choose the outdoor unit from that, then select the air handler whose blower can deliver the right cubic feet per minute through the ductwork that will actually exist after the visit. For a long one-story in Rio Vista that might mean a smaller cabinet than the one coming out. For a two-story in Ormond Lakes with a hot upstairs it might mean the same cabinet with zoning dampers and a variable blower that can serve one floor at a time.
Every air handler we install in Ormond Beach gets a float switch in the primary drain, a secondary pan under any attic unit, and a filter cabinet deep enough that the homeowner is not tempted back to the one-inch pleated filters that choke these returns. The crew comes from our Palm Coast headquarters, 26 miles up I-95, and the estimate is free. Call 866-266-5709.
Air handler questions from Ormond Beach homeowners
Can I keep my air handler and just replace the outdoor unit?
On a system under ten years old with a coil that matches the new refrigerant, sometimes. On the 1990s and 2000s systems we see in Tymber Creek and Breakaway Trails, no: the coil, the blower and the refrigerant are all from a different generation, and the mismatch costs you efficiency and the warranty.
Why is the return grille in my 1978 hallway so small?
Because the house was built for a smaller, less efficient system and a one-inch fiberglass filter. Modern coils need more air than that grille can pass, and the blower works harder to pull it. Enlarging the return or adding a second one is part of most retrofits west of Nova Road.
Should the air handler move out of the attic?
If there is a garage or interior closet with room, often yes. An attic in Ormond Beach runs well above 120 degrees in July, and every foot of duct and every cabinet seam up there is losing cooling to it. Moving the unit down also puts the drain pan somewhere a leak cannot stain a ceiling.
What does the variable-speed blower actually do for me?
It lets the system run slow and long, which dries the air better and keeps the back bedrooms from swinging. It also uses noticeably less electricity than the single-speed motors in most 1980s and 1990s cabinets, and it is the part of the system you hear the least.
Attic unit older than the house's second owner?
Free estimate on a matched Lennox air handler, with the ductwork looked at while we are up there.
